Had a chance to record some new footage of the exhaust. XForce Varex VMK51-250 variable volume exhaust – it’s pretty much straight through when it is open. Here’s a few runs with the back boxes set to closed and open for comparison. The engine is a BMW M20B25 with a crank from an M52B28 making it an M20B28. It has a dbilas 282°/272° camshaft. It’s running the original 80’s motronic from Bosch with a chip map design for the stroker conversion. It does pop a bit when the exhaust is warm and you change down. Would benefit from a more modern ECU and tuning (someday!)
The final trim piece is for the rear of the boot interior.
Here’s the initial planning using foam board.
Transferring the foam board to aluminium.
Test fit before bending.
Bends added, the left side needed a new piece adding and riveting to it during the test fit.
Applying glue to the vertical surfaces first.
Second stage was gluing down the rest of it. I’ve left a 1.5cm lip at the front to help the transition from this piece to the floor.
Test fit the carpeted version in the boot.
It’s not yet attached to the car and I still need to decide which rubber seals to use around it.
Next boot related project are the side panels. These I’m making out of aluminium, line with carpet and some rubber trim to seal them against the tub.
Passenger side panel is simpler, just a big triangle.
On the driver side there is the tank filler and the vent valve in the way. Here the first piece goes in for a test fit. This used to be one of the old small side panels from outside the boot area which is why there is glue all over it.
After a load of foam board templating I created this piece of aluminium. The black lines show where it needs bends.
After bending this comes a very solid piece.
Test fitting the bent piece.
This is the filler tube for the tank and the tank vent that this piece fits around.
The rest of the side panel is held on with rivnuts and bolts with cup washers. There’s not much room so these need to go in as two pieces and then joined.
To better secure the passenger side I created a 90º piece of aluminium and riveted it on. This means the back of the panel sits on the boot floor. In hindsight it would have been cleaner to add this as part of the main part, but the join will be hidden.
Ran into another clearance issue on the driver side – the spare wheel tub gets in they way.
To fix that I added a curve into the metal here – gives it about 1cm clearance from the spare wheel area of the tub.
Parts removed ready for carpet.
Driver side covered
Impact glue going on to the passenger side.
On the back of both side have rubber to reduce the chance of vibration and some JDM chopped tape. The sides are held in with a bolt into a rivnut. The rivnuts are mounted into the rear suspension towers.
The finished side panels with rubber edging added to close the gap to the tub. There are some very small wood screws holding the complex part into the boot floor. This is mostly to top that end wandering around.
On the passenger side the carpet is left long which better hides the edge.
Only one panel left to go for the rear. No more loosing small things forever out the back of the car!
I made some blanking plates to cover holes no longer needed in the tub.
These are aluminium, painted black then lined with rubber and held on with rivnuts, cup washers and bolts. Was thinking of leaving them shiny but ended up going for the subtle look.
This is the prototype with multiple bends, final two are new fresh ones with each bend only done once.
Final piece cut and bent, test fitting. A bit of blue tape to avoid scratching the paint.
Cleaned and painted
Applied a layer of 1mm rubber to the underside, I did this with double sided tape.
To mount these I added a rivnut to each part, M4 sized.
To attach to the car a hole was added in the new boot lid trim.
That cleanly attached these and closes up the gap nicely.
The cup washer and bolt are a bit smaller than those that hold the trim in, and they’re also a bit closer to the edge. However the style matches.
Bracket Number 1:
The return pipe from the radiator to the header tank has always been attached with a zip tie holder, but only double sided taped on. Every time the tape fails the hose is a bit flappy.
To fix this issue long terms I’ve stick a rivet into the bracket that holds the AFM
This is not going anywhere now.
Bracket Number 2:
Brake Servo vacuum hose holder
This attached to one of the bolts holding the rocker cover.
Up to now the hose sat on the rocker cover which has rubbed the paint away. Now there is plenty of clearance.
Runs as it did before, only with a gap to the top of the engine.
This is more of a closing panel than a bracket. There is a small hole pedal box into the engine bay behind the servo.
Can’t see it from up here with all the body work on, but should stop fumes getting into the cabin here.
This is a project that’s been been waiting for me to get to it for a very long time. The boot area has always been open with just two smaller panels either side.
One of the side panels shown here with plenty of Cat Aided Design help.
With the old side panels out I created a template out of cardboard.
Fine tuning of the cardboard template.
I’ve had this large piece of 1.5mm aluminium sat in storage for more than a year now!
Stuck the cardboard on the aluminium sheet, drew around the cardboard with a silver pen.
Using a mix of sheers and a nibbler I cut out the aluminium sheet. Wear gloves when using the nibbler, I didn’t have holes in my skin now ;o)
Using the nibbler always leaves you with a nice pile of aluminium curls.
The part is rough cut here, it’s taller than it needs to be.
Couple of loose bends based on the old side panels.
Used masking tape to protect the paint on the tub while test fitting this, it’s a couple cm above the height of the tub, so the next step is to mark up the final cuts.
This does a great job sealing the boot area, but it’s not very practical to get stuff into the boot!
Drawing up a lid/door for the boot area, the inner blue line show the opening, the outer line represents the overlap.
I will create the overlap using a tool you’d normally use for overlap welding two metal sheets on bodywork repair. It does an excellent job putting a clean bend into the metal, as long as you make sure it’s placed square to the work piece. Here’s the test piece. I got mine from Frost and is listed as a joggler / joddler or flanger! It also has a hole punch which can be useful but is a really good way to pinch your palms in the tool if you’re not careful!
Opening for the lid cut out – the aluminium was pretty floppy without the bends added. It’s much better now, but will also give the lid something to rest into.
The flanger only gets you so far into a corner leaving a square that needed to be shaped in a different way.
For this I used my vice and a sheet metal hammer.
Test fitted it in the car with the opening – the rivnuts holding this area have been in the tub since before it was painted! Note the boot floor is also new, it’s a little thinner than the original and no longer has holes for the 3 point harnesses I had before the new seat belts.
Next up, need something to close the opening up again. This is a fresh sheet of 2mm aluminium – just about managed to cut it with the sheer. I tried some test cuts with the angle grinder using a disk specifically for aluminium. It works fine but it leaves a rolled over flashing that takes quite a bit of clean up. The cut with the sheer is clean. It can add some light bends to the metal but those are not too bad to get out.
Square hole for the lock.
I got a new hinge, the brass one that I was using for mockup was too bulky (It was originally for the bonnet before I replace with stainless during the original build).
The wood floor is not thick enough to use wood screws to hold in the hinge, due to not being able to go buy stuff I custom made some ‘t nuts’ from some metal flat bar fixings I had in the parts bin. Drilled holes and tapped them for some M4 screws. Then used the router to add some recesses in the bottom of the floor.
I’ve also had a roll of carpet / speaker cloth sitting on top of a cupboard for ages, time to apply it to all the parts! Used impact spray glue. A bit of WD40 in a cloth is an easy way to get rid of overspray.
For the lid I’ve only applied carpet to one side, the intension is to add a brushed finish on the inside.
Luckily I had a tin of varnish in the cupboard to seal up the boot floor, gives it a fancy shade of oak for when I next look at the car from underneath – plus it give the MOT tester something nice too look at 😀
Added a block to the top side – this will be for mounting the sheet metal at the bottom. Cut the carpet around it, the only visible side is shown in this shot so I made sure the carpet covers it.
I think these brackets are from Ikea furniture, they were in the parts bin, combined them with some captive nuts.
Brackets in place holding the bottom of the sheet metal.
Here it is with everything in place, the inside of the lid still has the protective sheet on it, that’s something I’ll look at later.
Ordered some new stainless cup washers and bolts to match
I plan to add more panels inside the boot to stop small items disappearing and closing up more gaps where exhaust gas could come in.
The front wing stays rusted and broke again, did a temporary fix a few months ago, but finally it’s time to make some new ones which will hopefully be more resiliant to the elements.
Started with two 1 meter 10mm diameter solid rods
A piece of bar to turn into the bracket that will hold the rod on to the front uprights with a U clamp (51mm u clamp)
Bracket cut shown with U clamp.
Test fitted to the uprights
Used a clamp to hold the round bar to the bracket to get a it roughly lined up.
Used a caliper to evenly space the round bar away from the alloy wheels
Held in by hand for a better view of the bracket and round bar
Tack welded the round bar to the bracket
My temporary workshop setup – don’t recommend using a workmate for welding due to the risk of burning wood and fire. Use a metal welding table, which I don’t have in my garage. Grabbed the round bar quite far away from the weld so it was fine. Also used a TIG so no splatter.
I’m still a total amature at welding but these are OK
The main thing is that is holds together well. The angle grinder hides the bad.
One of the most time consuming parts of the build was creating a jig so that all four final bends ended up very similar.
It may only look like two bends, but there are hours of measuing, eyeing up and carefully deciding where the bends need to go.
The rod lines up with the holes on the carbon wings.
Now here’s one of those things that happens all too often on a project – the rods ended up 10mm too high on the first go. This is jig MK2 with the height adjusted. It did mean having to straighten out the rod and rebend it to the right position.
Here’s a test fit of the front of the rod bent into place
The jig is holding the back up.
Left to right the mount positions are little way off on the back, so some creative bending and P clip positioning evens out the rod placement.
The back bent into shape, again two bends took many hours to get to the right position.
Here are the P clips that will mount the wings to the rod
First test fit of the driver side, got some really nice new A4 grade cup washers, bolts and nuts from Westfield Fastners to finish it off.
Test fit on the passenger side. The wing was too close to the tyre so this one needed a bit more fine tuning to get it right.
A view from underneath with the wheel off.
There is enough gap between the tyre and the carbon, looks quite close from this angle. If there are problems it is easy to tweak the bends to create more clearance.
Before and after, the before is version 3 of the mounts which also failed eventually.
Ahh shiny parts!
Woolies sell rot free carpet, I thought it would be worth a try see how well it will last in a car without any interior weather proofing.
Here’s the before shot:
Trace the reverse shape of the old rubber mats on to the back of the new carpet. I used a silver pen.
Decided to purchase a good set of scissors/tailors shears, which cost nearly as much as the carpet but were well worth it. After the initial cut I had to give the edged a bit of a ‘hair cut’ to smooth it out. In future I want to look at better edge finishing.
Here’s the new carpet test fitted on the passenger side.
Both sides fitted
Another major irritation, and a safety issue was the rubber mats moving around on the driver side. It was held down with velcro but that kept coming off the rubber. For the carpet Woolies sells these poppers.
Once pushed through and attached the black ring with the spikes starts to disappear into the carpet.
Finally the button that the carpet pops on to needs to be mounted into the floor. The floor has a layer of sound deadening and a layer of carpet before getting to the new carpet. As such the button needed a bit of spacing form the floor. Due to a lack of available parts I ended up using some spare M4 nylocs.
I also have rubber mats under the seats and behind the seats. You can’t get to the ones under the seats unless you take the seats out so those are staying rubber for now. The rear carpets however I’ve also changed to carpet.
Some future thoughts on this, finishing the edging on the carpet is something I want to look into. I also got heel rest material – which is a textured rubber piece which would be good to put on the drivers side. Need to take the seats out and add carpet underneath. Removing the seats will also allow access to add poppers for the rear carpet.
So the MOT tester is a beast of a man and ripped both handbrake cables clean off the mounts! Better it failed here than in an emergancy though.
The orginal handbrake adjusters are bolts with the head of a bolt chopped, the end drilled with the lathe and a recess to capture the shorted handbrake cable with a spot of weld.
As the handbrake cables were now shorter than before the bolts were too short. These were extended by chopping the machines part off the old bolt and welded on to a new bolt making it longer. The recess needed drilling out again to remove old handbrake cable.
If this fails again it will need new handbrake cables.
The torn ends zipped tie down to make them easier to clean up for welding
Cables welded back on
Finally mounted back into the handbrake handle and adjusted. Hand brake retested with better results than the rear brakes!
The car was also failed on emission first time round as the machine was set wrong. HC limit for an 88 engine is 1200, it comes in around 650 – which as been the same for a numbr of years now. They incorrectly wanted to see less than 18 – keep an eye for that one, page 12 of this document is useful if you need paperwork: https://assets.publishing.service.gov.uk/government/uploads/system/uploads/attachment_data/file/676700/in-service-exhaust-emission-standards-for-road-vehicles-19th-edition.pdf
Another week, another new fluid all over the floor! Coolant this time from the rear port on the cylinder head. That’s the pipe that goes to the interior heater core:
Took it off and cleaned everything up on the head
New coolant flange gasket fresh from eBay!
Eveything fitted back together (after dropping the bolts…). It’s a little bit fiddly getting this back on with the battery tray in the way. The bolt seen in the follow photo on the left of the image is much higher up than you’d think.
The nice thing about the Sporters, more room to get behind the engine is just 4 bolts away!
