Boot interior rear

The final trim piece is for the rear of the boot interior.

Here’s the initial planning using foam board.

Transferring the foam board to aluminium.

Test fit before bending.

Bends added, the left side needed a new piece adding and riveting to it during the test fit.

Applying glue to the vertical surfaces first.

Second stage was gluing down the rest of it. I’ve left a 1.5cm lip at the front to help the transition from this piece to the floor.

Test fit the carpeted version in the boot.

It’s not yet attached to the car and I still need to decide which rubber seals to use around it.
