Windscreen part 1

To fit the windscreen you’ll need some masking tape a pencil, rule and maybe a tape measure!

  • Put some tape down and mark a centre line on the scuttle – I used the bonnet hinge and my guide which was previous painstakingly placed in the middle!
  • Place the ali cover that goes under the screen on the scuttle measuring 130mm back from the scuttle edge (back edge inside car) on both sides. Also mark 60mm back.
  • Mark 7mm out from the metal edge – this creates a slot shop that the windscreen sides can drop into. Got to be careful that the holes are parallel with the edges of the screen!
  • Drill a series of holes inside the marked area, cut and file them out. Now you can drop the screen to test fit! That’s about as far as we got this weekend!

<p>Windscreen loosly slotted through the scuttle</p>

Windscreen loosely slotted through the scuttle

<p>Stainless plates do a good job of covering holes chopped into the scuttle.</p>

Stainless plates do a good job of covering holes chopped into the scuttle.

<p>With the screen pulled back the metal of the screen frame pretty much touches the scuttle</p>

With the screen pulled back the metal of the screen frame pretty much touches the scuttle

<p>Screen should provide a decent amount of wind protection. Side screen may still need to be fitted!</p>

Screen should provide a decent amount of wind protection. Side screen may still need to be fitted!

<p>The driver side - the bottom hole just bolts in with a spacer, not sure yet how the top bolts in yet as the brackets have a huge bend in them that don't seem to line up with anthig.</p>

The driver side – the bottom hole just bolts in with a spacer, not sure yet how the top bolts in yet as the brackets have a huge bend in them that don’t seem to line up with anything.

<p>The ali panel under the screen is not the right shape but once the rubber strip is added it almost fills the gaps - some filling work will be need to make it fit better.</p>

The ali panel under the screen is not the right shape but once the rubber strip is added it almost fills the gaps – some filling work will be need to make it fit better.

All we need now are some wishbones!
