Varex exhaust build part 3

Built the other side of the exhaust today. Welding is ‘better’ than when I started but still pretty uneven. I can’t weld too far consistently around the curve yet. Did punch a few holes in the metal in places which results in having to ‘glob’ in filler rod to build it back up again. This part was back gassed as on the others before as it was a butt joint.

The 45º and straight pieces are sleeve fit, have welded these too so less clamps are needed. It also cuts down on potential exhaust leaks.

Once the two back boxes were hung I used some boxes and various peices of wood to hold the tips in place at the right height, this is with the car on the ground. Nothing on the Sportster is straight so this was done visually.

I used a piece of angle metal to line the tops and ends of the tips up. This helped make sure the tips were aligned  straight with the ground, with each other and spaced from the back of the car.

Welding the tips on was a bit tricky, blew a few holes in the metal especially where the gaps were bigger. The left box alignment is slighly off, but it’s not visible once mounted and the tips are in the right place visually.

Both exhaust pipes mounted, the v-bands are visible in this shot. I used a tiny bit of exhaust paste on the mating surface, shouldn’t be needed with v-bands but I’d rather not have to take them off again! Also visible the zip tie exhaust hanger, nothing like attaching your exhaust to your suspension ;o)  Kinds tempted to make some straight pipes that can be put in place of the back boxes, but that’s a whole new level of noise (did try running it with just the header and you need to wear ear protection…)

The more permanent hanger, this is a part is from pypes a US manfuacturer of exahust pipes. Had that left over from building an exhaust for the Mustang (http://www.mustang67.co.uk/exhaust-upgrade/) last year. Available at https://www.summitracing.com/

View from the otherside, wiring is hanging down. These cables need plumbing in properly and the metal shields putting back on the mufflers.

Car down on the ground from a low angle, the exahust tips are closer together than before (due to the input on the backbox being offset rather than in the middle).

The tips stick out a little further than the old ones, the wall thickness and slash cut work quite nicely.

Temporarily wired up the control box, and now for the noise test:

Closed it’s quieter than the jetex micro bullet muffers + the magnaflow boxes. Open it’s a bit of a beast, louder than before so that should be fun 😉 It’s pretty much were I wanted it to be, will see what it’s like on the road once the wiring is done.
